Shunt Trip and Undervoltage release

UNDERVOLTAGE TRIP UNIT LAT. LEFT 110Vac FOR Mbs32N

MAANLLA-110

+

Type

Shunt trip

Control voltage (V)

110 50/60Hz

Rated insulation voltage Ui (V)

690

Rated impulse Withstand Voltage Uimp (kV)

6

Frequency

50/60 Hz

Suitable for

MBS32NG, MBS32NH, MBS63NH

Operation temperature (°C)

-25/+60

Storage temperature

-50/+80 °C

Mounting

left side

Standard connection terminals

-- mm²

Torque

-- Nm

Standard

EN 60947-1/-2/-4-1

Approvals

CE, UL

State

On sale

Brand

AEG
