Voltage monitoring and phase failure relay
RELE' DI CONTROLLO TENSIONE/SEQUENZA 1CO
E1YM
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Type
Multifunction
Technical Feautures
3ph and 1ph voltage control
Adjustment
0,1s...10s
Control voltage (V)
400/230 AC
Rated insulation voltage Ui (V)
4000
Contacts
1CO
Power loss
1 W
Protection degree
IP40 HOUSING (IP20 terminals)
Number of modules
1
Mounting
On DIN rail 35 mm according to EN 50022
Operation temperature (°C)
-25/+55
Storage temperature
-25/+70 °C
Standard connection terminals
1 or 2 x 0,5...2,5 mm²
Torque
1 Nm
Approvals
CE
State
On sale
