Thermal overload relays for Mini Contactors
AEG THERMAL OVERLOAD RELAY b05N 0,41…0,55A
B05N-0.55
RELE' TERMICO AEG SERIE B05N PER MONTAGGIO DIRETTO SU MINICONTATTORI SERIE LS05K E LS06K, CLASSE 10, CONTATTI 1NO+1NC, RESET MANUALE O AUTOMATICO, PROTEZIONE PER MANCANZA FASE, FUNZIONI TEST E STOP, INDICAZIONE DI SCATTATO SUL FRONTE, COMPENSAZIONE IN TEMPERATURA, ADATTI PER IMPIEGO TRIFASE E MONOFASE
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Protection
Overcurrent and phase failure
Thermal setting Ir (A)
0,41...0,55
Rated Operational Voltage Ue (V)
690 AC
Rated insulation voltage Ui (V)
690
tripping class
10
Frequency
50/60 Hz
Auxiliary Contacts
1NO+1NC
Ith auxiliary contact in the base unit (A)
6 for NC / 4 for NO
Power Loss for each pole (W)
1,1...2
Connections
screw
Standard connection terminals
1 or 2 x 0,75...4 mm²
Torque
1,1...1,5 Nm
Mounting
Direct on the contatcor
Suitable for
LS05K 3 poles, LS06K
Operation temperature (°C)
-25/+60
Storage temperature
-50/+80 °C
Protection Degree on terminals
IP20
Brand
AEG
Standard
EN60947-1, EN60947-5-1, EN60947-4-1
Approvals
UL, CSA
State
On sale
