Series EC90
MCB AEG EPC60 4P C 6kA 4A 2mod.
EPC64C04
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
4 A
Number of Poles
4
Rated Breaking Capacity
6 kA
Characteristic
C (5 - 10 In)
Standard
EN60947-2, EN60898
Short circuit capacity acc. to EN60947-2 at 230Vac
6 kA
Short circuit capacity EN60947-2 at 400V
6 kA
Number of modules
2
Power loss
5,4 W
Rated Voltage AC
230/400 V
Min-Max operating voltage AC
12-250/440 V
Frequency
50/60 and DC Hz
Rated Voltage DC
96 V
Standard connection terminals
1…16 mm²
Isolator application according to EN 60947-2
YES
Working temperature
-25/+55 °C
Storage temperature
-55/+55 °C
Approvals
VDE
Calibration Temperature (°C)
30
Current limitation class
3
Mounting
any (except upside down)
State
On sale
Brand
AEG
