Series EC90
MCB AEG EC90 1P+N C 6kA 2A 1mod.
EC91C02NR
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
2 A
Number of Poles
1+N
Rated Breaking Capacity
6 kA
Characteristic
C (5 - 10 In)
Standard
EN 60898
Short circuit capacity acc. to EN60947-2 at 230Vac
10 kA
Short circuit capacity EN60947-2 at 400V
-- kA
Number of modules
1
Power loss
2,20 W
Rated Voltage AC
230 V
Min-Max operating voltage AC
12-250/440 V
Frequency
50/60 Hz
Rated Voltage DC
- V
Standard connection terminals
1…16 mm²
Isolator application according to EN 60947-2
YES
Working temperature
-25/+55 °C
Storage temperature
-55/+55 °C
Approvals
VDE, KEMA, IMQ
Calibration Temperature (°C)
30
Current limitation class
3
State
On sale
Brand
AEG
