SERIES D90 – HD90 1+N RCBOs
RCBO AEG 1P+N C 32A 10kA 30mA AC
D90SC32/030
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Compatible products
Technical Specifications
Rated Current (A)
32 A
Rated Breaking Capacity
10 kA
Residual current
30 mA
Fault Current Type
AC
Characteristic
C (5 - 10 In)
Number of Poles
1+N
Standard
EN 61009
Number of modules
2
Power loss
7,4 W
Rated Voltage AC
230 V
Min-Max operating voltage AC
100-255 V
Frequency
50/60 Hz
Short circuit capacity acc. to EN60947-2 at 230Vac
15 kA
Residual making and breaking capacity IDm (A)
10000
Isolator application according to EN 60947-2
YES
Working temperature
-5/+60 °C
Storage temperature
-25/+70 °C
Calibration Temperature (°C)
30
Approvals
VDE
Standard connection terminals
top 16- bottom 25 mm²
State
On sale
Brand
AEG
