SERIES D90 – HD90 1+N RCBOs
RCBO AEG 1P+N B 20A 6kA 30mA AC
D90B20/030
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Compatible products
Technical Specifications
Rated Current (A)
20 A
Rated Breaking Capacity
6 kA
Residual current
30 mA
Fault Current Type
AC
Characteristic
B (3 - 5 In)
Number of Poles
1+N
Standard
EN 61009
Number of modules
2
Power loss
5,6 W
Rated Voltage AC
230 V
Min-Max operating voltage AC
100-255 V
Frequency
50/60 Hz
Short circuit capacity acc. to EN60947-2 at 230Vac
10 kA
Residual making and breaking capacity IDm (A)
6000
Isolator application according to EN 60947-2
YES
Working temperature
-5/+60 °C
Storage temperature
-25/+70 °C
Calibration Temperature (°C)
30
Approvals
KEMA
Standard connection terminals
top 16- bottom 25 mm²
State
On sale
Brand
AEG
