Manual motor starters MBS63N
SALVAMOTORE AEG Mbs63NH 62-73A
MBS63NH-730
SALVAMOTORI AEG CON COMANDO ROTATIVO SERIE MBS63NH, CORRENTE NOMINALE DA 30A FINO A 80A, TENSIONE DI IMPIEGO 690VAC, TENSIONE DI ISOLAMENTO 1000V, FREQUENZA 50/60HZ, CAPACITA' DI ROTTURA 50KA A 400VAC
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
73 A
Rated power 3 phase motor (kW) at 400V
37
3 phase Horsepower HP @ 200-208V 60Hz UL508
20
3 phase Horsepower HP @ 220-240V 60Hz UL508
25
3 phase Horsepower HP @ 440-480V 60Hz UL508
50
3 phase Horsepower HP @ 575V 60Hz UL508
60
tripping class
10A
Thermal setting Ir (A)
62...73
Magnetic setting Im
1022 A
Rated insulation voltage Ui (V)
1000
Rated Operational Voltage Ue (V)
690 AC
Frequency
50/60 Hz
Rated impulse Withstand Voltage Uimp (kV)
8
Power loss
20,76 W
Ultimate breaking capacity Icu at 230 V AC
30 kA
Ultimate breaking capacity Icu at 400/415V AC
30 kA
Ultimate breaking capacity Icu at 500 V AC
10 kA
Ultimate breaking capacity Icu at 690 V AC
8 kA
Rated service short-circuit breaking capacity Ics at 400V
30 kA
isolator application
YES
Mechanical life
50.000 operations
Electrical Life at In
25.000
Working temperature
-25/+60 °C
Storage temperature
-50/+80 °C
Protection degree
IP20 Housing (IP10 Main terminals)
Standard connection terminals
1 or 2 x 1...50 mm²
Torque
4 Nm
Approvals
CE
Standard
EN 60947-1/-2/-4-1
Brand
AEG
