Manual Motor Starters Mbs25N
MANUAL MOTOR STARTER SCHALT Mbs25N 0,4 -0,63A
MBS25N-006
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
0,63 A
Thermal trip unit setting range
0,4...0,6 A
Magnetic setting Im
9
Rated insulation voltage Ui (V)
690
Rated Operational Voltage Ue (V)
690 AC
Conventional thermal current Ith (A)
25
Ultimate breaking capacity Icu at 230 V AC
50 kA
Ultimate breaking capacity Icu at 400 V AC
50 kA
Ultimate breaking capacity Icu at 500 V AC
50 kA
Ultimate breaking capacity Icu at 690 V AC
50 kA
Category of use
A (IEC 947-2); AC-3 (IEC 947-4-1)
Mechanical life
100.000 operations
Electrical Life at In
100.000 operations
Number of operations/hour
25
Number of modules
2,5
Power loss
6 W
Standard connection terminals
1...6 mm²
Torque
1,8 Nm
Approvals
UL, CSA
State
On sale
