Manual Motor Starters AEG Mbs32N
SALVAMOTORE AEG Mbs32NG 25-32A
MBS32NG-320
SALVAMOTORE AEG SERIE Mbs32NG, TARATURA TERMICA DA 0,25 A 32A, CLASSE DI INTERVENTO 10A, POTENZA MOTORE TRIFASE DA 0,09KW A 15KW, TENSIONE NOMINALE 690VAC, TENSIONE DI ISOLAMENTO 690V, FREQUENZA 50/60HZ
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
32 A
Type
MBS32NG
Rated power 3 phase motor (kW) at 400V
15
tripping class
10A
Thermal setting Ir (A)
25...32
Magnetic setting Im
480A
Rated insulation voltage Ui (V)
690
Rated Operational Voltage Ue (V)
690 AC
Frequency
50/60 Hz
Rated impulse Withstand Voltage Uimp (kV)
6
Power loss
9,30 W
Ultimate breaking capacity Icu at 230 V AC
10 kA
Ultimate breaking capacity Icu at 400 V AC
10 kA
Ultimate breaking capacity Icu at 440 V AC
6 kA
Ultimate breaking capacity Icu at 500 V AC
4 kA
Ultimate breaking capacity Icu at 690 V AC
2 kA
Ultimate breaking capacity Icu at 250 V DC
_ kA
Rated service short-circuit breaking capacity Ics at 400V
10 kA
isolator application
YES
Mechanical life
100.000 operations
Electrical Life at In
50.000 cycles
Working temperature
-25/+55 °C
Storage temperature
-50/+80 °C
Protection degree
IP20 Housing (IP10 Main terminals)
Standard connection terminals
1...4 mm²
Torque
1,2 Nm
Approvals
UL
Standard
EN60947-2, EN60947-4-1, EN60947-1
State
On sale
Brand
AEG
