Fused loadbreak disconnectors
SWITCH DISCONNECTOR WITH FUSE HSLN3S 4P 800A
HSLN3S4800
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Type
Fuse switch disconnector
Rated Current (A)
800 A
Number of Poles
3+N
Rated insulation voltage Ui (V)
1000
Rated impulse Withstand Voltage Uimp (kV)
12
Rated Current in category AC-21A (A) at 400/500/690V
800/800/800
Rated current in category AC-22A (A) at 400/500/690V
800/800/800
Rated current in category AC-23A (A) at 400/500/690V
630/500/400
Rated fuse short circuit current (kA)
50
Power Loss for each pole (W)
30
Electrical Life at In
1.000 operations
Mechanical life
4000 operations
Standard connection terminals
busbar 2x40x6 mm²
Brand
SCHALT
