Fused loadbreak disconnectors
SWITCH DISCONNECTOR WITH FUSE HSLN3S 4P 630A
HSLN3S4630
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
630 A
Number of Poles
3+N
Fuse type
NH3
Rated insulation voltage Ui (V)
1000
Rated Current in category AC-21A (A) at 400/500/690V
630/630/630
Rated current in category AC-22A (A) at 400/500/690V
630/630/630
Rated current in category AC-23A (A) at 400/500/690V
630/500/400
Rated power 3 phase motor (kW) at 400V
330
Rated fuse short circuit current (kA)
50
Electrical Life at In
1.000 operations
Mechanical life
4000 operations
Power Loss for each pole (W)
30
Standard connection terminals
busbar 2x40x5 mm²
Weight
14,5
Brand
SCHALT
