Fused loadbreak disconnectors
SWITCH DISCONNECTOR WITH FUSE HSLN0S 4P 125A
HSLN0S4125
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Type
Fuse switch disconnector
Rated Current (A)
125 A
Number of Poles
3+N
Rated insulation voltage Ui (V)
1000
Rated impulse Withstand Voltage Uimp (kV)
12
Rated Current in category AC-21A (A) at 400/500/690V
125/125/125
Rated current in category AC-22A (A) at 400/500/690V
125/125/125
Rated current in category AC-23A (A) at 400/500/690V
125/100/80
Rated fuse short circuit current (kA)
50
Power Loss for each pole (W)
4,8
Electrical Life at In
1.000 operations
Mechanical life
8000 operations
Standard connection terminals
busbar 16x4 mm²
Brand
SCHALT
