Fused loadbreak disconnectors
SWITCH DISCONNECTOR WITH FUSE HSLN000S 4P 100A
HSLN000S4100
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Type
Fuse switch disconnector
Rated Current (A)
100 A
Number of Poles
3+N
Rated insulation voltage Ui (V)
1000
Rated impulse Withstand Voltage Uimp (kV)
8
Rated Current in category AC-21A (A) at 400/500/690V
100/100/100
Rated current in category AC-22A (A) at 400/500/690V
80/80/80
Rated current in category AC-23A (A) at 400/500/690V
80/63/45
Rated fuse short circuit current (kA)
50
Power Loss for each pole (W)
1,2
Electrical Life at In
1.500
Mechanical life
10.000 operations
Standard connection terminals
busbar 14x3 mm²
Standard
EN 60947-1; EN 60947-3
Approvals
CE
State
On sale
Brand
SCHALT
