Fused loadbreak disconnectors
SWITCH DISCONNECTOR WITH FUSE HSLN00S 3P 160A
HSLN00S3160
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Type
Fuse switch disconnector
Rated Current (A)
160 A
Number of Poles
3
Rated insulation voltage Ui (V)
1000
Rated impulse Withstand Voltage Uimp (kV)
12
Rated Current in category AC-21A (A) at 400/500/690V
160/160/160
Rated current in category AC-22A (A) at 400/500/690V
160/160/160
Rated current in category AC-23A (A) at 400/500/690V
160/125/100
Rated fuse short circuit current (kA)
50
Power Loss for each pole (W)
4,8
Electrical Life at In
1.000 operations
Mechanical life
8000 operations
Standard connection terminals
busbar 16x4 mm²
Brand
SCHALT
