Fused loadbreak disconnectors
SWITCH DISCONNECTOR WITH FUSE HSLN000S 3P 100A
HSLN000S3100
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Type
Fuse switch disconnector
Rated Current (A)
100 A
Number of Poles
3
Rated insulation voltage Ui (V)
1000
Rated impulse Withstand Voltage Uimp (kV)
8
Rated Current in category AC-21A (A) at 400/500/690V
100/100/100
Rated current in category AC-22A (A) at 400/500/690V
100/100/100
Rated current in category AC-23A (A) at 400/500/690V
80/63/45
Rated closing/breaking current at 400V AC23 (A)
1000
Short time current Icw x 0,25s (kA)
10
Short time current Icw x 1s (kA)
5
Admissible power AC3 at 400V (kW)
52
Rated fuse short circuit current (kA)
50
Power Loss for each pole (W)
1,2
Electrical Life at In
1.500
Mechanical life
10.000 operations
Standard connection terminals
busbar 14x3 mm²
Torque
8 Nm
Standard
EN 60947-1; EN 60947-3
Approvals
CE
State
On sale
Brand
SCHALT
