Elfa NEXT DC90, HDC90
RCBO AEG 2P C 20A 10kA 30mA A
HDC90SC20/030
INTERRUTTORE MAGNETOTERMICO DIFFERENZIALE COMPATTO 2 POLI IN 2 MODULI CORRENTE NOMINALE DA 6A A 40A TENSIONE NOMINALE 230VAC TENSIONE DI IMPIEGO MIN-MAX 155-265V CON POTERE DI INTERRUZIONE 4,5KA 6KA E 10KA SECONDO EN61009-1 E 6KA 10KA E 15KA SECONDO EN60947-2 CLASSE AC A E AI AINTERPURBAZIONE SOGLIE DIFFERENZIALI DI 10mA 30mA e 300mA
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
20 A
Rated Breaking Capacity
10 kA
Residual current
30 mA
Fault Current Type
A
Characteristic
C (5 - 10 In)
Number of Poles
2
Number of modules
2
Power loss
5,04 W
Rated Voltage AC
230 V
Min-Max operating voltage AC
150-265 V
Frequency
50/60 Hz
Short circuit capacity acc. to EN60947-2 at 230Vac
10 kA
Residual making and breaking capacity IDm (A)
6000
Isolator application according to EN 60947-2
YES
Working temperature
-25/+60 °C
Storage temperature
-25/+70 °C
Calibration Temperature (°C)
30
Standard
EN 61009
Standard connection terminals
25 top bottom mm²
Approvals
IMQ
State
On sale
Brand
AEG
