Contators LSN from 55kW to 200kW 3 poles
CONTACTOR AEG 200kW 3P 1NO+1NC 110V 50/60Hz
LS200N3011-AJ
CONTATTORI AEG SERIE LSN, POTENZA NOMINALE IN AC3 DA 55KW A 200KW, TENSIONE DI COMANDO DA 24VAC, 110VAC E 230VAC
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Admissible power AC3 at 400V (kW)
200
Number of Poles
3
Control voltage (V)
110 (50Hz); 110...120 (60Hz)
Rated Operational Voltage Ue (V)
1000
Ie current cat. AC3 (A)
370
3 phase Horsepower HP @ 200-208V 60Hz UL508
125
3 phase Horsepower HP @ 220-240V 60Hz UL508
150
3 phase Horsepower HP @ 440-480V 60Hz UL508
300
3 phase Horsepower HP @ 575V 60Hz UL508
350
Single phase Horsepower HP @ 230V 60Hz UL508
--
Ohmic load AC1
600 A
Auxiliary Contacts
1NO+1NC
Rated insulation voltage Ui (V)
1000
Frequency Range
25...400 Hz
Power Loss for each pole (W)
72
Breaking Capacity
8xIe AC-3 acc. to IEC601947-4-1 kA
Coil Operating Range
0,85...1,1 x Uc
Coil pick-up power at 50/60Hz or DC
475VA
Coil holding power at 50/60Hz or DC
17,5VA
Ith auxiliary contact in the base unit (A)
16
Operation temperature (°C)
-40/+70
Storage temperature
-40/+70 °C
Max backup fuse
630A gG
Connections
bar
Standard connection terminals
240 mm²
Standard
EN60947-1 / EN60947-4-1
Approvals
CE, UL
Brand
AEG
State
On sale
