ADD ON RCCB FOR MCBs SERIES E90

ADD-ON RCD AEG Elfa HD9 4P <32A 500mA A

HD9432/500

+

Downloads and Resources

Download informative and technical materials to learn more about the features of our products.

Click here for download: Product data sheet

Click here for download: Dimensioned drawing

Technical Specifications

Rated Current (A)

32 A

Residual current

500 mA

Fault Current Type

A

Number of Poles

4

Standard

EN 61009

Number of modules

4

Power loss

5,49 W

Rated Voltage AC

415 V

Min-Max operating voltage AC

205-455 V

Nuisance tripping resistance

up to 250A

Frequency

50/60 Hz

Working temperature

-25/+60 °C

Storage temperature

-25/+70 °C

Approvals

KEMA

Brand

AEG
