T Series
TIME RELAY DELAY ON 1CO 24-240V AC/DC
T-ONE
TEMPORIZATORE CON RITARDO ALL'ECCITAZIONE 24-240VAC/24-48VDC 1CO, TEMPORIZZAZIONE 0,05s...100h.
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Type
ON delay
Control voltage (V)
24-240 AC / 24-48 DC
Frequency
50/60 and DC Hz
Adjustment
7 range from 0,05s to 100h
Consumption
35VA max.
Rated Operational Voltage Ue (V)
250
Rated current Ie AC-15 at 240V
3A
Rated current Ie DC-13 at 24V
2 A
Contacts
1CO
Mechanical life
30 milion operations
Electrical Life at In
100.000 operations
Working temperature
-20/+60 °C
Storage temperature
-40/+85 °C
Standard
EN 61812.1
Approvals
CE, EMC, RoHS
State
On sale
Brand
AEG
Megiston
