RECLOSING DEVICE AEG ADVANCED MCB+CT 10kA 4P 40A
SUTPE94SC40
RIARMO AUTOMATICO ASSEMBLATO CON INTERRUTTORE AUTOMATICO E TOROIDE SEPARATO (ACCESSORIO), CORRENTE NOMINALE 40A, 4 POLI, TENSIONE NOMINALE 415VAC, POTERE DI INTERRUZIONE NOMINALE 10KA SECONDO EN60898, CAPACITA' DI ROTTURA 15KA SECONDO EN60947-2, RIARMO CON TEST DEL CIRCUITO, SOGLIE E NUMERO TENTATIVI COMPLETAMENTE PROGRAMMABILI A DISPLAY.
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Compatible products
Technical Specifications
Type
Reclosing system and MCB
Rated Current (A)
40 A
Number of Poles
4
Characteristic
C (5 - 10 In)
Standard
EN 60947-2
Rated Breaking Capacity
10 kA
Number of modules
6,5
Power loss
12 W
Rated Voltage AC
415 V
Frequency
50/60 Hz
numebr of reclosing attemps
Settable
Short circuit capacity EN60947-2 Icu at 400V
15 kA
Service breaking capacity Ics (%Icu)
50%
Standard connection terminals
1…35 mm²
Isolator application according to EN 60947-2
YES
Working temperature
-10/+50 °C
Diameter (mm)
--
Brand
AEG
Megiston
