StartUp 2 HDC90
RECLOSING DEVICE AEG RCBO HDC 2P 16A 30mA A
SU2HDSC16/030
SISTEMA COMPLETO DI RIARMO AUTOMATICO CON TEST DEL CIRCUITO, CORRENTE NOMINALE 16A, TENSIONE NOMINALE 230VAC, 2 POLI, 2 MODULI, POTERE DI CORTOCIRCUITO 10KA, SOGLIA DIFFERENZIAEL 30MA, CLASSE A, CURVA C, 3 TENTATIVI DI RIARMO
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
16 A
Rated Breaking Capacity
10 kA
Residual current
30 mA
Fault Current Type
A
Characteristic
C (5 - 10 In)
Number of Poles
2
Number of modules
4,5
Power loss
4,2 W
Rated Voltage AC
230 V
Frequency
50/60 Hz
numebr of reclosing attemps
3
Short circuit capacity acc. to EN60947-2 at 230Vac
10 kA
Residual making and breaking capacity IDm (A)
6000
Isolator application according to EN 60947-2
YES
Working temperature
-25/+55 °C
Storage temperature
-25/+65 °C
Standard
EN 61009
Standard connection terminals
25 top bottom mm²
Approvals
CE
Brand
AEG
State
On sale
