RECLOSING DEVICE AEG RCCB 2P 40A 30mA Ai
REC2AI240/30
RIARMO AUTOMATICO ACCOPPIATO CON INTERRUTTORE DIFFERENZIALE PURO CON TEST DEL CIRCUITO, CORRENTE NOMINALE 40A, TENSIONE NOMINALE 230VAC, 2 POLI, 4,5 MODULI, SOGLIA DIFFERENZIALE 30MA, CLASSE AI ANTIPERTURBAZIONE, 3 TENTATIVI DI RIARMO
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
40 A
Residual current
30 mA
Fault Current Type
Ai high withstand capability
Number of Poles
2
Standard
EN 61008
Number of modules
4,5
Rated Voltage AC
230 V
Frequency
50/60 Hz
numebr of reclosing attemps
3
Residual making and breaking capacity IDm (A)
500
Conditional residual short circuit current Idc (A)
10000
Power loss
6,86 W
Nuisance tripping resistance
up to 3000A
isolator application
YES
Working temperature
-25/+40 °C
Brand
AEG
