SERIES EFI,EHFI,ESHFI RCCBs
RCCB AEG Elfa FPSI 40A 4P 300mA Asi
FPSI40/300-4
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
40 A
Residual current
300 mA
Fault Current Type
A Selective high withstand capability
Number of Poles
4
Standard
EN 61008
Number of modules
4
Power loss
10,29 W
Rated Voltage AC
240/415 V
Min-Max operating voltage AC
180/455 V
Frequency
50/60 Hz
Residual making and breaking capacity IDm (A)
500
Conditional residual short circuit current Idc (A)
10000
Nuisance tripping resistance
up to 5000A
isolator application
YES
Working temperature
-25/+60 °C
Storage temperature
-25/+70 °C
Approvals
VDE, KEMA
Brand
AEG
