SERIES EFI,EHFI,ESHFI RCCBs
DIFFERENZIALE PURO AEG Elfa FPA 80A 4P 30mA F
FPF480/030
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
80 A
Residual current
30 mA
Fault Current Type
AF
Number of Poles
4
Standard
EN 61008
Number of modules
4
Power loss
24,9 W
Rated Voltage AC
240/415 V
Min-Max operating voltage AC
180/455 V
Frequency
50/60 Hz
Residual making and breaking capacity IDm (A)
500
Conditional residual short circuit current Idc (A)
10000
Nuisance tripping resistance
up to 3000A
isolator application
YES
Working temperature
-25/+60 °C
Storage temperature
-25/+70 °C
Approvals
VDE
Brand
AEG
