DIN MCCB MCXT1
MCCB AEG MCXT1 4P 125A 70KA TMD InN=100%
MCXT1H4125N
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Compatible products
Technical Specifications
Protection
Thermomagnetic
Number of Poles
3+N
Rated Current (A)
125 A
Ultimate breaking capacity Icu at 400/415V AC
70 kA
Ultimate breaking capacity Icu at 440 V AC
65 kA
Ultimate breaking capacity Icu at 500 V AC
50 kA
Ultimate breaking capacity Icu at 690 V AC
10 kA
Service breaking capacity Ics (%Icu)
50% a 415VAC
Rated Operational Voltage Ue (V)
690 AC
Rated insulation voltage Ui (V)
800
Category of use
A
Suitable for use as a isolator
YES
Thermal setting Ir (A)
0,7...1In
Magnetic setting Im
10 In
Neutral protection
50%
Number of modules
6
Mechanical life
25000 operations CO
Electrical Life at In
8.000 operations
Power loss
32,1 W
Standard connection terminals
50 mm²
Torque
3 Nm
Approvals
CE
Brand
AEG
State
On sale
