DIN MCCB MCXT1
MCCB AEG MCXT1 3P 40A 18KA TMD
MCXT1B3040
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Compatible products
Technical Specifications
Protection
Thermomagnetic
Number of Poles
3
Rated Current (A)
40 A
Ultimate breaking capacity Icu at 400/415V AC
18 kA
Ultimate breaking capacity Icu at 440 V AC
15 kA
Ultimate breaking capacity Icu at 500 V AC
8 kA
Ultimate breaking capacity Icu at 690 V AC
3 kA
Service breaking capacity Ics (%Icu)
100% a 415VAC
Rated Operational Voltage Ue (V)
690 AC
Rated insulation voltage Ui (V)
800
Category of use
A
Suitable for use as a isolator
YES
Thermal setting Ir (A)
0,7...1In
Magnetic setting Im
450 A
Neutral protection
100%
Number of modules
4,5
Mechanical life
25000 operations CO
Electrical Life at In
8.000 operations
Power loss
7,88 W
Standard connection terminals
50 mm²
Torque
3 Nm
Approvals
CE
Brand
AEG
State
On sale
