Modular disconnectors SZD up to 200A
SEZIONATORE SCHALT SZD2 3P 200A
SZD23200
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Type
Modular switch
Rated Current (A)
200 A
Number of Poles
3
Number of modules
4
Rated Operational Voltage Ue (V)
690 AC
Rated insulation voltage Ui (V)
800
Rated impulse Withstand Voltage Uimp (kV)
8
Rated Current in category AC-21A (A) at 400/500/690V
200/160/160
Rated current in category AC-22A (A) at 400/500/690V
200/160/160
Rated current in category AC-23A (A) at 400/500/690V
160/125/100
Rated power in AC23 (kW) at 415/500/690V
69/83/90
Rated closing/breaking current at 400V AC23 (A)
1600/1280
Short time current Icw x 1s (kA)
3
Rated fuse short circuit current (kA)
50 (fusibile gG 1256A)
Power loss
9 W
Mechanical life
30.000
Electrical Life at In
1.000 operations
Standard connection terminals
70 mm²
Torque
6 Nm
Width
65,6 mm
Height
113 mm
Depth
81 mm
Standard
EN 60947-1; EN 60947-3
Approvals
CE
State
On sale
Brand
SCHALT
