RD1N, RD3N, RDB
SEPARATED RCD SCHALT B 1CO 0,05-5A 230VAC RS485
RDB230RS
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Residual current
30mA...30A mA
Contacts
1CO
Fault Current Type
B
Rated Operational Voltage Ue (V)
230 AC
Number of modules
2
Response time tA
0...30s
Frequency
50 Hz
Reset
on device
Reset mode setting
Manual/automatic
Operating of the trip contacts
Standard or positive
Operation temperature (°C)
0...+50
Storage temperature
-20/+70 °C
Protection degree
IP40 HOUSING (IP20 terminals)
Standard connection terminals
2,5 mm²
Output
RS485
Standard
EN60947-2, EN62423
State
On sale
