People Protection
RCCD AEG DAG+ 2P 25A A 2M
DAG225/30
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
25 A
Residual current
30 mA
Fault Current Type
A
Number of Poles
2
Standard
EN 61008
Number of modules
2
Power loss
1 W
Rated Voltage AC
230/400 V
Operating Voltage of circuit TEST (V) AC
110 - 254
Frequency
50/60 Hz
Residual making and breaking capacity IDm (A)
1000
Conditional residual short circuit current Idc (A)
6000 (with breaker or fuse gC 63A)
Nuisance tripping resistance
up to 250A
Protection degree
IP40 HOUSING (IP20 terminals)
Working temperature
-25/+40 °C
Storage temperature
-40/+70 °C
Mechanical life
20000 operations CO
Standard connection terminals
25 top bottom mm²
Torque
2,8 Nm
Mounting
any
Approvals
IMQ
State
On sale
Brand
AEG
