RCCBs B TYPE F TYPE
RCCB AEG Elfa EHBFI 80A 4P 300mA Type B
EHBFI80/300-4
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Compatible products
Technical Specifications
Rated Current (A)
80 A
Residual current
300 mA
Fault Current Type
B
Number of Poles
4
Standard
EN 61008
Number of modules
4
Power loss
24,9 W
Rated Voltage AC
240/415 V
Min-Max operating voltage AC
205-455 V
Frequency
50/60 Hz
Residual making and breaking capacity IDm (A)
500
Conditional residual short circuit current Idc (A)
10000
isolator application
YES
Nuisance tripping resistance
up to 3000A
Working temperature
-25/+40 °C
Storage temperature
-25/+70 °C
Brand
AEG
