RCBO AEG DDM+ 1+N 10A 4,5KA A 2M
DDM45A10/030
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
10 A
Residual current
30 mA
Number of Poles
1+N
Number of modules
2
Characteristic
C (5 - 10 In)
Fault Current Type
A
Rated Breaking Capacity
4,5 kA
Short circuit capacity acc. to EN60947-2 at 230Vac
6 kA
Standard
EN 61009
Power loss
2,3 W
Rated Voltage AC
230 V
Min-Max operating voltage AC
170 - 254 V
Frequency
50 Hz
Current limitation class
3
Residual making and breaking capacity IDm (A)
3000
Protection degree
IP40 HOUSING (IP20 terminals)
Working temperature
-5/+55 °C
Storage temperature
-40/+70 °C
Standard connection terminals
25 top bottom mm²
Torque
2 Nm
Mounting
any
Mechanical life
20000 operations CO
Supply from
Top/Bottom terminals
Approvals
IMQ
State
On sale
Brand
AEG
