Polyester Box type SGA

POLYESTER IP66 ENCLOSURE PLAIN DOOR W300xH800xD230

SGA83

+

Downloads and Resources

Download informative and technical materials to learn more about the features of our products.

Click here for download: Product data sheet

Technical Specifications

Door

Plain

Type

300x800

Insulation class

II

Rated insulation voltage Ui (V)

1500

Protection degree

IP66

Body

REINFORCED POLYESTER

Impact resistance

IK10

Colour

RAL 7035

Operation temperature (°C)

-30/+70

Rated Width

300 mm

Rated Height

800 mm

Rated Depth

230 mm

Maximum heating dissipation (W)

103

Brand

SCHALT

Approvals

CE
