Phase sequence and phase failure relay
RELE' DI CONTR.SEQUENZA E MANCANZA FASE
E1PF
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Type
monitoring phase sequence and phase failure
Control voltage (V)
400/230 AC
Rated insulation voltage Ui (V)
4000
Contacts
1CO
Power loss
0,8 W
Protection degree
IP40 HOUSING (IP20 terminals)
Number of modules
1
Mounting
On DIN rail 35 mm according to EN 50022
Operation temperature (°C)
-25/+55
Storage temperature
-25/+70 °C
Standard connection terminals
1 or 2 x 0,5...2,5 mm²
Torque
1 Nm
Approvals
CE
State
On sale
