Motorized changeover switches 2-layers
MOTORIZED CHANGEOVER SWITCH HLN3S 3P 315A 220VAC
CSHLN3SM3315
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
315 A
Number of Poles
3
Rated insulation voltage Ui (V)
1500
Control voltage (V)
220 AC
Rated Current in category AC-21A (A) at 400/500/690V
250/250/250
Rated current in category AC-22A (A) at 400/500/690V
250/250/250
Rated current in category AC-23A (A) at 400/500/690V
250/200/160
Rated closing/breaking current at 400V AC23 (A)
2500/2000
Short time current Icw x 1s (kA)
8
Short time current Icw x 0,25s (kA)
16
Rated fuse short circuit current (kA)
50 (fuse 315A)
Mechanical life
10.000 operations
Electrical Life at In
2000 operations
Power Loss for each pole (W)
6,3
Standard connection terminals
185 mm²
Approvals
CE
State
On sale
