Motorized changeover switches 2-layers
MOT.CHANGEOVER SWITCH HLN8S 3P 2500A 220VAC/24VDC
CSHLN8SM32500
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
2500 A
Number of Poles
3
Rated insulation voltage Ui (V)
1500
Control voltage (V)
110-220 AC / 24 DC
Rated Current in category AC-21A (A) at 400/500/690V
2500/2000/1250
Rated current in category AC-22A (A) at 400/500/690V
-/-/-
Rated current in category AC-23A (A) at 400/500/690V
-/-/-
Rated closing/breaking current at 400V AC23 (A)
--
Short time current Icw x 1s (kA)
50
Short time current Icw x 0,25s (kA)
100
Rated fuse short circuit current (kA)
--
Mechanical life
2500 operations
Electrical Life at In
500 operations
Power Loss for each pole (W)
91,7
Standard connection terminals
-- mm²
Approvals
CE
State
On sale
