Motorized changeover switches 2-layers
MOT.CHANGEOVER SWITCH HLN7S 4P 1600A 220VAC/24VDC
CSHLN7SM41600
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
1600 A
Number of Poles
3+N
Rated insulation voltage Ui (V)
1500
Control voltage (V)
110-220 AC / 24 DC
Rated Current in category AC-21A (A) at 400/500/690V
1600/1250/1250
Rated current in category AC-22A (A) at 400/500/690V
1250/-/-
Rated current in category AC-23A (A) at 400/500/690V
-/-/-
Rated closing/breaking current at 400V AC23 (A)
--
Short time current Icw x 1s (kA)
50
Short time current Icw x 0,25s (kA)
100
Rated fuse short circuit current (kA)
--
Mechanical life
4000 operations
Electrical Life at In
500 operations
Power Loss for each pole (W)
38,3
Standard connection terminals
-- mm²
Approvals
CE
State
On sale
