Motorized changeover switches 2-layers
MOT. CHANGEOVER SWITCH HLN6S 3P 1000A 220VAC/24VDC
CSHLN6SM31000
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
1000 A
Number of Poles
3
Rated insulation voltage Ui (V)
1500
Control voltage (V)
110-220 AC / 24 DC
Rated Current in category AC-21A (A) at 400/500/690V
1000/1000/1000
Rated current in category AC-22A (A) at 400/500/690V
1000/1000/1000
Rated current in category AC-23A (A) at 400/500/690V
1000/800/630
Rated closing/breaking current at 400V AC23 (A)
10000/8000
Short time current Icw x 1s (kA)
50
Short time current Icw x 0,25s (kA)
100
Rated fuse short circuit current (kA)
100 (fuse 1000A)
Mechanical life
4000 operations
Electrical Life at In
1.000 operations
Power Loss for each pole (W)
24,3
Standard connection terminals
-- mm²
Approvals
CE
State
On sale
