Motorized changeover switches 2-layers
MOTORIZED CHANGEOVER SWITCH HLN5S 4P 630A 220VAC
CSHLN5SM4630
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
630 A
Number of Poles
3+N
Rated insulation voltage Ui (V)
1500
Control voltage (V)
110-220 AC / 24 DC
Rated Current in category AC-21A (A) at 400/500/690V
630/630/630
Rated current in category AC-22A (A) at 400/500/690V
630/630/630
Rated current in category AC-23A (A) at 400/500/690V
630/500/400
Rated closing/breaking current at 400V AC23 (A)
6300/5040
Short time current Icw x 1s (kA)
26,5
Short time current Icw x 0,25s (kA)
53
Rated fuse short circuit current (kA)
50 (fuse 630A)
Mechanical life
8000 operations
Electrical Life at In
1500 operations
Power Loss for each pole (W)
15,6
Standard connection terminals
2x185 mm²
Approvals
CE
State
On sale
