Motorized changeover switches 2-layers
MOTOR.CHANGEOVER SWITCH HLN4S 3P 400A 220VAC/24VDC
CSHLN4SM3400
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
400 A
Number of Poles
3
Rated insulation voltage Ui (V)
1500
Control voltage (V)
110-220 AC / 24 DC
Rated Current in category AC-21A (A) at 400/500/690V
400/400/400
Rated current in category AC-22A (A) at 400/500/690V
400/400/400
Rated current in category AC-23A (A) at 400/500/690V
400/315/250
Rated closing/breaking current at 400V AC23 (A)
4000/3200
Short time current Icw x 1s (kA)
13
Short time current Icw x 0,25s (kA)
26
Rated fuse short circuit current (kA)
50 (fuse 400A)
Mechanical life
8000 operations
Electrical Life at In
1500 operations
Power Loss for each pole (W)
9,4
Standard connection terminals
240 mm²
Approvals
CE
State
On sale
