Auxialiary Circuists Switching
SWITCH AEG 1NO 16A 250V AC
ASTS1610
INTERRUTTORE NON AUTOMATICO 1NO 16A IN ACCORDO A EN 60669-1 TENSIONE NOMINALE 250/415VAC TENSIONE MINIMA 24VAC FREQUENZA 50HZ CORRENTE DI BREVE DURATA 3KA INGOMBRO 0.5 MODULI
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Rated Current (A)
16 A
Contacts
1NO
Rated Voltage AC
250 V
Min-Max operating voltage AC
24-250 V
Number of modules
0,5
Power loss
0,32 W
Isolator application according to EN 60947-3
YES
Standard
EN 60669-1, VDE 0632 Part 101
Rated fuse short circuit current (kA)
3
Standard connection terminals
1 or 2x1,5 mm²
Torque
1,2 Nm
Working temperature
-25/+55 °C
Storage temperature
-40/+70 °C
Brand
AEG
Approvals
CE
State
On sale
