Modular changeover switches SD
CHANGEOVER SWITCH SD2 4P 125A
SD2/4-125
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Compatible products
Technical Specifications
Rated Current (A)
125 A
Contacts
4NO + 4NO
Rated insulation voltage Ui (V)
800
Rated impulse Withstand Voltage Uimp (kV)
8
Conventional thermal current Ith (A)
125
Rated Current in category AC-21A (A) at 400/500/690V
125/125/125
Rated current in category AC-22A (A) at 400/500/690V
125/125/125
Rated current in category AC-23A (A) at 400/500/690V
100/63/32
Rated closing/breaking current at 400V AC23 (A)
1000/800
Short time current Icw x 1s (kA)
1,5
Rated fuse short circuit current (kA)
20 (fusibile gG 125A)
Number of modules
8
Mechanical life
30.000
Electrical Life at In
1.000 operations
Power Loss for each pole (W)
3
Standard connection terminals
50 mm²
Torque
2,5 Nm
Standard
EN 60947-1; EN 60947-3
Approvals
CE
State
On sale
