MCXT4
INTERRUTTORE AUTOMATICO AEG MCXT4 4P 63A 70KA LSIG
MCXT4H4063LSIG
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Protection
Line Electronic and Earth Fault (LSIG)
Number of Poles
4
Rated Current (A)
63 A
Ultimate breaking capacity Icu at 400/415V AC
70 kA
Ultimate breaking capacity Icu at 500 V AC
50 kA
Ultimate breaking capacity Icu at 690 V AC
15 kA
Service breaking capacity Ics (%Icu)
100%
Rated Operational Voltage Ue (V)
690 AC
Rated insulation voltage Ui (V)
1000
Category of use
A (IEC 60947-2)
Suitable for use as a isolator
YES
Thermal setting Ir (A)
--
Magnetic setting Im
--
Overload channel LT
Ir=0,4...1 In
Time band classes LTD
5, 10, 20
Short-circuit channel ST
Ist= Off, 1...10 In
Time setting bands STD (s)
0,05...0,4
Instantaneus short-circuit protection channel I
Off, 1..10 In
Ground fault protection
0,2...1 In
Neutral protection
0 - 50% - 100%
Mechanical life
25000 operations
Electrical Life at In
8.000 operations
Power loss
4,2 W
Standard connection terminals
25x8,5 mm²
Torque
8 Nm
Approvals
CE
State
On sale
