MCXT4
INTERRUTTORE AUTOMATICO AEG MCXT4 3P 80A 50KA MA
MCXT4S3080MA
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Protection
Motor Thermomagnetic
Number of Poles
3
Rated Current (A)
80 A
Ultimate breaking capacity Icu at 400/415V AC
50 kA
Ultimate breaking capacity Icu at 500 V AC
36 kA
Ultimate breaking capacity Icu at 690 V AC
12 kA
Service breaking capacity Ics (%Icu)
100%
Rated Operational Voltage Ue (V)
690 AC
Rated insulation voltage Ui (V)
1000
Category of use
A (IEC 60947-2)
Suitable for use as a isolator
YES
Thermal setting Ir (A)
--
Magnetic setting Im
400..600..800A
Overload channel LT
--
Time band classes LTD
5, 10, 20
Short-circuit channel ST
--
Time setting bands STD (s)
--
Instantaneus short-circuit protection channel I
--
Ground fault protection
--
Neutral protection
--
Mechanical life
25000 operations
Electrical Life at In
8.000 operations
Standard connection terminals
25x8,5 mm²
Torque
8 Nm
Approvals
CE
State
On sale
