MCXT4
INTERRUTTORE AUTOMATICO AEG MCXT4 3P 160A 36KA LSI
MCXT4N3160LSI
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Technical Specifications
Protection
Line Electronic (LSI)
Number of Poles
3
Rated Current (A)
160 A
Ultimate breaking capacity Icu at 400/415V AC
36 kA
Ultimate breaking capacity Icu at 500 V AC
30 kA
Ultimate breaking capacity Icu at 690 V AC
10 kA
Service breaking capacity Ics (%Icu)
100%
Rated Operational Voltage Ue (V)
690 AC
Rated insulation voltage Ui (V)
1000
Category of use
A (IEC 60947-2)
Suitable for use as a isolator
YES
Thermal setting Ir (A)
--
Magnetic setting Im
--
Overload channel LT
Ir=0,4...1 In
Time band classes LTD
5, 10, 20
Short-circuit channel ST
Ist= Off, 1...10 In
Time setting bands STD (s)
0,05...0,4
Instantaneus short-circuit protection channel I
Off, 1..10 In
Ground fault protection
--
Neutral protection
0 - 50% - 100%
Mechanical life
25000 operations
Electrical Life at In
8.000 operations
Power loss
27 W
Standard connection terminals
25x8,5 mm²
Torque
8 Nm
Approvals
CE
State
On sale
