MCXT7
MCCB AEG MCXT7 4P 800A 70KA EL. LSIG
MCXT7H4800G
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Compatible products
Technical Specifications
Protection
Line Electronic and Earth Fault (LSIG)
Number of Poles
4
Rated Current (A)
800 A
Ultimate breaking capacity Icu at 400/415V AC
70 kA
Ultimate breaking capacity Icu at 500 V AC
50 kA
Ultimate breaking capacity Icu at 690 V AC
42 kA
Service breaking capacity Ics (%Icu)
100%
Rated Operational Voltage Ue (V)
690 AC
Rated insulation voltage Ui (V)
1000
Category of use
B
Suitable for use as a isolator
YES
Overload channel LT
Ir=0,4...1 In
Time band classes LTD
Adjustable from 3 to 144 s
Short-circuit channel ST
Ist=Off, 0,6...10 In
Time setting bands STD (s)
0,1...0,8
Instantaneus short-circuit protection channel I
Off, 1,5...15 In
Ground fault protection
Off, 0,1...1 In
Neutral protection
0 - 50% - 100%
Mechanical life
20.000 operations
Electrical Life at In
3000 operations
Power loss
72 W
Standard connection terminals
50x20 mm²
Torque
18 Nm
Approvals
CE
State
On sale
