MCXT7
MCCB AEG MCXT7 3P 1250A 50KA EL. MI
MCXT7S31250MI
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Compatible products
Technical Specifications
Protection
Electronic Magnetic only Motor (SI)
Number of Poles
3
Rated Current (A)
1250 A
Ultimate breaking capacity Icu at 400/415V AC
50 kA
Ultimate breaking capacity Icu at 500 V AC
45 kA
Ultimate breaking capacity Icu at 690 V AC
30 kA
Service breaking capacity Ics (%Icu)
100%
Rated Operational Voltage Ue (V)
690 AC
Rated insulation voltage Ui (V)
1000
Category of use
B
Suitable for use as a isolator
YES
Overload channel LT
--
Time band classes LTD
--
Short-circuit channel ST
--
Time setting bands STD (s)
--
Instantaneus short-circuit protection channel I
Off, 1..10 In
Ground fault protection
--
Neutral protection
--
Mechanical life
20.000 operations
Electrical Life at In
3000 operations
Power loss
171 W
Standard connection terminals
50x20 mm²
Torque
18 Nm
Approvals
CE
State
On sale
