MCXT7
MCCB AEG MCXT7 3P 1000A 70KA G LS/I
MCXT7H31000G/I
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Compatible products
Technical Specifications
Protection
Electronic Generator (G LS/I)
Number of Poles
3
Rated Current (A)
1000 A
Ultimate breaking capacity Icu at 400/415V AC
70 kA
Ultimate breaking capacity Icu at 500 V AC
50 kA
Ultimate breaking capacity Icu at 690 V AC
42 kA
Service breaking capacity Ics (%Icu)
100%
Rated Operational Voltage Ue (V)
690 AC
Rated insulation voltage Ui (V)
1000
Category of use
B
Suitable for use as a isolator
YES
Overload channel LT
Ir=0,4...1 In
Time band classes LTD
Adjustable from 3 to 6 s
Short-circuit channel ST
Ist= Off, 1...10 In
Time setting bands STD (s)
0,05...0,2
Instantaneus short-circuit protection channel I
Off, 1..10 In
Ground fault protection
--
Neutral protection
0 - 50% - 100%
Mechanical life
20.000 operations
Electrical Life at In
3000 operations
Power loss
111 W
Standard connection terminals
50x20 mm²
Torque
18 Nm
Approvals
CE
State
On sale
