MCXT5
MCCB AEG MCXT5 4P 400A 50KA TMA InN=50%
MCXT5S4400
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Compatible products
Technical Specifications
Protection
Thermomagnetic Line
Number of Poles
4
Rated Current (A)
400 A
Ultimate breaking capacity Icu at 400/415V AC
50 kA
Ultimate breaking capacity Icu at 500 V AC
30 kA
Ultimate breaking capacity Icu at 690 V AC
25 kA
Service breaking capacity Ics (%Icu)
100%
Rated Operational Voltage Ue (V)
690 AC / 750 DC
Rated insulation voltage Ui (V)
1000
Category of use
A (IEC 60947-2)
Suitable for use as a isolator
YES
Thermal setting Ir (A)
280..340..400
Magnetic setting Im
2000.3000..4000 A
Overload channel LT
--
Time band classes LTD
--
Short-circuit channel ST
--
Time setting bands STD (s)
--
Instantaneus short-circuit protection channel I
--
Ground fault protection
--
Neutral protection
50%
Mechanical life
20.000 operations
Electrical Life at In
7.000 operations
Power loss
72,3 W
Standard connection terminals
32,5x10 mm²
Torque
36 Nm
Approvals
CE
State
On sale
