MCXT3
MCCB AEG MCXT3 4P 200A 50KA TMD InN=50%
MCXT3S4200
+
Error loading products: {{ error }}
Downloads and Resources
Download informative and technical materials to learn more about the features of our products.
Compatible products
Technical Specifications
Protection
Thermomagnetic Line
Number of Poles
4
Rated Current (A)
200 A
Ultimate breaking capacity Icu at 400/415V AC
50 kA
Ultimate breaking capacity Icu at 500 V AC
30 kA
Ultimate breaking capacity Icu at 690 V AC
6 kA
Ultimate breaking capacity Icu at 250 V DC
50 (2 poles in serial) kA
Ultimate breaking capacity Icu at 500 V DC
_ kA
Service breaking capacity Ics (%Icu)
50%
Rated Operational Voltage Ue (V)
690 AC / 500 DC
Rated insulation voltage Ui (V)
800
Category of use
A (IEC 60947-2)
Suitable for use as a isolator
YES
Thermal setting Ir (A)
140...200
Magnetic setting Im
2000 A
Neutral protection
50%
Mechanical life
25000 operations
Electrical Life at In
8.000 operations
Power loss
39,6 W
Standard connection terminals
24x8 mm²
Torque
8 Nm
Approvals
CE
State
On sale
